Construction: 14, 16, 18 gauge welded steel Dimensions: W20" X D20" X H 21" Adjustable internal 3 position stand (adjusts to 12", 16" or 20") Drawer Dimensions: W16" X D16" X H8" -2 drawer cabinet W16" X D16" X H5" -3 drawer cabinet W16" X D16" X H3" -5 drawer cabinet Function: To easily and securely store lap top computers with the ability to recharge batteries and download/upload data. Also for storage of other test equipment

• Available in 2, 3, or 5 drawer models
• Drawers and cabinet vented on bottom and sides
• Data connection to each drawer is by a coiled cord with RJ45 or RJ25 jack, drawer offers additional opening for second data connection
• Power supplied to each drawer by a UL approved 16 gauge coiled cord with 3 prong grounded outlet
• Each drawer has a cam lock all keyed differently with 2 master keys per cabinet
• Built-in adjustable stands. Height set at 12" easily adjusts to 16" or 20" in approximately 2 minutes
• Cabinets can be stacked 2 high. Remove stand from top cabinet and bolt to lower cabinet in any direction, front & front, or front & side allowing for convenient and complete storage needs
• No installation necessary; simply remove from carton, plug-in main power supply located on back of cabinet and connect modem jacks to back of cabinet. Cabinet is then ready to securely store lap top computers or test equipment with the capability to recharge and/or download data while the laptop
• Cabinets are painted with highly durable powder coat paint Standard color: Stealth Blue with custom colors available

• Fan mounted at bottom of cabinet for extreme conditions.

Model Numbers:

LL2 – Laptop Lock-up® 2 drawer cabinet
LL3 – Laptop Lock-up® 3 drawer cabinet (with adjustable stand)
LL5 – Laptop Lock-up® 5 drawer cabinet (with adjustable stand)
LL10 – Laptop Lock-up® 10 drawer cabinet

Click here to download printable specifications

Laptop Lock-Up® Operating Instructions

Laptop Lock-Up® 5 Drawer Stacking Instructions

Zero Maintenance / Warranty Info.

Stand Height Adjustment Instructions

Wall / Floor Mounting Instructions
